CC695 tunnel car wash machine

📋 General Information

• Product Name: 14 Brushes Tunnel Car Wash Machine

• Model: CC-695

• Ordering Cycle: 25 days

• Validity Period: 30 days

• Place of Delivery: Qingdao, China

💰 Quotation & Commercial Terms

Terms & Notes:

1. Payment Term: 30% T/T deposit to start manufacturing, 70% T/T balance before shipping out.

2. Package Info: 1 * 20ft container can accommodate up to 2 machine sets.

3. Manufacturing Time: 15 days.

4. Installation Service: Client arranges airfare, food, and hotel accommodation for technicians.

📐 Technical Specifications & Data

• Overall Dimension: 16.38m × 3.8m × 3.44m

• Conveyor Length: 17.28m (including conveyor guide)

• Installation Required Space: 17.58m × 4.0m

• Voltage Requirement: AC380V 50Hz (5-wire system)

• Water Supply Requirement: Pipe diameter DN25, Flow ≥ 200L/min

• Air Supply Requirement: Pressure 0.75–0.9 Mpa / Flow ≥ 0.1m³/min

• Ground Flatness Requirement: Error ≤ 10mm

• Applicable Vehicles: Cars / Jeeps / Vans (under 10 seats)

• Max Car Wash Size: 5.3m × 2.1m × 2.1m (Wheelbase ≤ 3.2m)

• Car Wash Speed: 45–55 cars/hour

• Water Consumption: 155 L/car

• Power Consumption: 0.8 kWh/car

• Shampoo Consumption: 20–40 ml/car

• Wax Consumption: 30 ml/car

⚙️ Functional Configurations & Systems

• Hot-dipped Galvanized Steel Frame: 1 group

• Shampoo System: 1 group

• Wax System: 1 group

• Air Drying System: 1 group

• Car Entrance Guide System: 1 group

• Intelligent Control System: Data management, checking, & operation

• Self-Diagnosis System: Automatic fault display & self-checking

• Up-and-Down Lifting Top Brush: 1 set

• Short Vertical Brushes: 4 sets

• Fixed Open & Close Long Vertical Brushes: 2 sets

• Movable Open & Close Long Side Brushes: 2 sets

• Side Drying Brushes: 2 sets

• Top Drying Brush: 1 set

• High-Pressure Water Device: Optional

• Chassis Spray System: Optional

• Swing Air Drying System: Optional

🔧 Key Brand Components

🌟 Key Product Features & Advantages

1. Proven Technology: Originally from Japan with over 15 years of industry-leading performance in China.

2. Professional Image: Modern exterior elevates store branding and attracts premium customers.

3. Labor Saving: Fully automated operation replaces 3–4 workers, reducing significant annual labor expenses.

4. High Revenue Potential: Multi-function washing options expand commercial service offerings.

5. High Efficiency: Washing capacity of over 500 cars per day for high throughput locations.

6. Water Saving: Eco-friendly design reduces water usage per wash cycle.

7. Energy Efficient: Optimized power consumption lowers daily operational costs.

8. Heavy-Duty Quality: Industrial-grade components deliver high reliability and cost-efficiency.

9. Enhanced Safety: Integrated explosion-proof and anti-lock safety protection features.

10. Easy Operation: One-touch operation starts wash modes with just two simple button presses.

11. Low Failure Rate: Premium imported components ensure stable 24/7 commercial performance.

12. Smart Troubleshooting: Built-in fault codes simplify diagnostic checks and maintenance.

13. Paint Protection: 4th generation gentle foam brushes protect vehicle finish.

14. Modular Design: Modular configuration allows easy upgrade options over time.

15. Eco-Friendly: Eco-safe consumables minimize environmental impact.

16. Reliable Service: Comprehensive after-sales technical support ensures continuous operations.
